| Total number of connection points | 2 | |
| Total number of potentials | 1 | |
| Color | transparent | |
| Pollution degree (1) | 2 | |
| Rated voltage EN (1) [V] | 400 | V |
| Rated surge voltage (1) [kV] | 4 | kV |
| Nominal current [A] | 24 | A |
| Connection technology (1) | PUSH WIRE® | |
| Solid sizes 1 | 0.75 … 2.5 mm² / 18 … 12 AWG | |
| Strip length 1 | 12 mm / 0.47 in | |
| Type of wiring | Side-entry wiring | |
| Weight [g] | 1.847 | g |
| Width | 9.2 mm / 0.362 in | |
| Height | 13.1 mm / 0.516 in | |
| Length | 19.5 mm / 0.768 in | |
| Safety information 1 | In grounded power lines |
